Flow range

±0.03ft/s ~ ±40ft/s (±0.01m/s ~ ±12m/s)

Accuracy

±0.5% of measured value (for ±1.5ft/s~±40ft/s)

Pipe size

1 in to 200 in (25mm to 5000mm)

Fluid

Water, Sea Water, Diesel Oil, Kerosene, Gasoline , Fuel Oil, Gasoline, Propane (-45℃), Alcohol, Butane (0℃) ℃Water (125℃), Other

Pipe material

Carbon Steel, PVC, Stainless Steel, Asbestos, Cast Iron, Aluminum, Ductile Iron, Fiber Glass-Epoxy, Copper, Other

Function Specifications

Optional Outputs

Analog output: 4~20mA, max load 750Ω.
Pulse output: 0~9999Hz, OCT, (min. and max. frequency is adjustable) Realy output: SPST, max 1Hz,(1A@125VAC or 2A@30VDC)

Communication interface

WIFI, RS232&RS485

SD Card

Standard SD card Max record:512days Record time interval

Power supply

90 to 245 VAC, 48 to 63 Hz. Or 10 to 36VDC

Keypad

22 keys with tactile action

Display

40 character, 2 line (20X2) lattice alphanumeric, back lit LCD.

Temperature

Transmitter:14℉~122℉(-40℃~60℃)
Transducer:32℉~176℉(-40℃~80℃)

Humidity

Up to 99% RH,non-condensing

Physical Specifications

Transmitter

NEMA 4X (IP65), Die-cast aluminum

Transducer

Encapsulated design
double-shielded transducer cable
Standard/maximum cable length:30ft/1000ft(9m/305m)

Transducer cable

Standard cable length:30ft(9m).

Weight

Transmitter:approximately 2.15kg;
Transmitter:approximately 0.9kg.

Type of Temperature Sensor

PT100

PT100 Temperature sensor

PT1000

PT1000 Temperature sensor
