Drying surface
35 x 45 cm
Gel capacity
16 mini (8 x 7 cm) gels, 9 Criterion™ (13.3 x 8.7 cm) gels, 2 large (20 x 20 cm) gels, 1 sequencing gel
Gel support plate
Porous polypropylene, 120 µm average pore size
Sealing gasket
Transparent silicone rubber
Vacuum source
Minimum ultimate vacuum of 25" Hg pump with a rating of 28" Hg or better and a capacity of 20–30 L/min recommended
Operating temperature
50–90°C
Operating time
5 min to 9 hr 55 min
Operating cycles
3 programmable cycles (PAGE gel, sequencing, gradient) for various gel types
LED display
Dryer temperature, time left in drying cycle
Regulatory certification
CE, EN 61010-1
Dimensions (W x D x H)
55 x 50 x 11 cm
Weight
9.8 kg (22 lb) |
|
|
